99.98%, 99.99%
Vacuum Molten Salt Electrolysis
Ningbo Chuangrun Base/Harbin Borui Base
-0.1mm; 0.1-0.5mm; 0.5-1mm; 1-2mm; 2-10mm
Vacuum sealed
100 kg
Semiconductor, Aerospace, Aviation
| Quantity: | |
|---|---|
Project | Ultra-low Oxygen Titanium Crystal | Low-oxygen Titanium Crystal | Unit | Detection Method |
Total Purity | ≥99.99 | ≥99.98 | % [wt] | - |
Fe | ≤5 | ≤10 | ppm [wt] | GDMS |
Al | ≤5 | ≤10 | ppm [wt] | GDMS |
Cu | ≤5 | ≤10 | ppm [wt] | GDMS |
V | ≤5 | ≤10 | ppm [wt] | GDMS |
Mn | ≤20 | ≤100 | ppm [wt] | GDMS |
Si | ≤1 | ≤5 | ppm [wt] | GDMS |
Sn | ≤0.01 | ≤1 | ppm [wt] | GDMS |
Pb | ≤0.01 | ≤1 | ppm [wt] | GDMS |
As | ≤0.01 | ≤1 | ppm [wt] | GDMS |
其它 | ≤1 | ≤1 | ppm [wt] | GDMS |
C | ≤20 | ≤50 | ppm [wt] | LECO |
H | ≤10 | ≤50 | ppm [wt] | LECO |
O | ≤150 | ≤250 | ppm [wt] | LECO |
N | ≤10 | ≤50 | ppm [wt] | LECO |
Project | Ultra-low Oxygen Titanium Crystal | Low-oxygen Titanium Crystal | Unit | Detection Method |
Total Purity | ≥99.99 | ≥99.98 | % [wt] | - |
Fe | ≤5 | ≤10 | ppm [wt] | GDMS |
Al | ≤5 | ≤10 | ppm [wt] | GDMS |
Cu | ≤5 | ≤10 | ppm [wt] | GDMS |
V | ≤5 | ≤10 | ppm [wt] | GDMS |
Mn | ≤20 | ≤100 | ppm [wt] | GDMS |
Si | ≤1 | ≤5 | ppm [wt] | GDMS |
Sn | ≤0.01 | ≤1 | ppm [wt] | GDMS |
Pb | ≤0.01 | ≤1 | ppm [wt] | GDMS |
As | ≤0.01 | ≤1 | ppm [wt] | GDMS |
其它 | ≤1 | ≤1 | ppm [wt] | GDMS |
C | ≤20 | ≤50 | ppm [wt] | LECO |
H | ≤10 | ≤50 | ppm [wt] | LECO |
O | ≤150 | ≤250 | ppm [wt] | LECO |
N | ≤10 | ≤50 | ppm [wt] | LECO |
